TP-LINK
TP-Link TL-SG1008P 8-Port Giagbit PoE Switch, 4 POE ports, IEEE 802.3af, Max Output 53W
$78.98 CAD
/
Shipping calculated at checkout.
Item model number: TL-SG1008P
- Form Factor:External
- Connectivity Technology:Wired
- Data Transfer Rate:16 Gbps
- Data Link Protocol:Ethernet Fast Ethernet Gigabit Ethernet
- Networking / Ports Qty:8
- Width:6.7 Inch
- Depth:3.9 Inch
Specification
| Ports & interfaces | |||
|---|---|---|---|
| Copper ethernet cabling technology | 1000BASE-T,100BASE-TX,10BASE-T | Gigabit Ethernet (copper) ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) | Basic switching RJ-45 Ethernet ports quantity | 8 |
| Networking | |||
|---|---|---|---|
| Full duplex | Yes | 10G support | No |
| Flow control support | Yes | Networking standards | IEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3u,IEEE 802.3x |
| Auto MDI/MDI-X | Yes | ||
| Data transmission | |||
|---|---|---|---|
| Store-and-forward | Yes | MAC address table | 8000 entries |
| Switching capacity | 16 Gbit/s | ||
| Design | |||
|---|---|---|---|
| Rack mounting | No | Colour of product | Grey |
| LED indicators | Status | ||
| Design | |||
|---|---|---|---|
| Certification | FCC, CE | ||
| Power | |||
|---|---|---|---|
| Power connector | DC-in jack | Number of power supply units | 1 |
| Power consumption (typical) | 53 W | ||
| Power over Ethernet (PoE) | |||
|---|---|---|---|
| Power over Ethernet (PoE) ports quantity | 4 | Power over Ethernet (PoE) | Yes |
| Operational conditions | |||
|---|---|---|---|
| Operating relative humidity (H-H) | 10 - 90% | Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90% | Storage temperature (T-T) | -40 - 70 °C |
| Weight & dimensions | |||
|---|---|---|---|
| Width | 171 mm | Height | 27 mm |
| Depth | 98 mm | ||
| Packaging content | |||
|---|---|---|---|
| User guide | Yes | ||
