TP-LINK
TP-Link TL-SF1008P 10/100Mbps 8-Port PoE Switch, 4 POE ports, IEEE 802.3af, 53W
$59.98 CAD
/
Shipping calculated at checkout.
Item model number: TL-SF1008P
- Supports PoE power up to 15.4W for each PoE port Supports PoE power up to 53W for all PoE ports
- Standards and Protocols: IEEE802.3, 802.3u, 802.3x, 802.3af, CSMA/CD,
- TCP/IP Ports: 8x 10/100M Auto-Negotiation RJ45 ports with 4 PoE ports (port-1~port-4), Auto MDI/MDIX
- Basic Function: Compatible with IEEE 802.3af compliant PDs Port Priority Function
- Wire-speed Performance MAC Address Auto-Learning and Auto-aging IEEE802.;3x flow control for Full-Duplex Mode and backpressure for Half-Duplex Mode;Backbound Bandwidth: 1.6Gbps MAC Address Table: 1k Forwarding Rate: 10BASE-T: 14880pps/port 100BASE-TX: 148800pps/port;Industry-leading 5-year warranty and unlimited technical support. Technical Support: +1 866 225 8139; Hotline en Français: +1 855 987 5465.;
Specification
| Management features | |||
|---|---|---|---|
| Switch type | Unmanaged network switch | ||
| Ports & interfaces | |||
|---|---|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 8 | ||
| Networking | |||
|---|---|---|---|
| Full duplex | Yes | Flow control support | Yes |
| Networking standards | IEEE 802.3 | Auto MDI/MDI-X | Yes |
| Data transmission | |||
|---|---|---|---|
| Maximum data transfer rate | 0.1 Gbit/s | Store-and-forward | Yes |
| MAC address table | 1000 entries | ||
| Protocols | |||
|---|---|---|---|
| Supported network protocols | CSMA/CD, TCP/IP, PPF | ||
| Design | |||
|---|---|---|---|
| Stackable | No | Colour of product | Black |
| Certification | FCC, CE | ||
| Power | |||
|---|---|---|---|
| Power connector | DC-in jack | Power consumption (typical) | 53 W |
| Power over Ethernet (PoE) | |||
|---|---|---|---|
| Power over Ethernet (PoE) | Yes | ||
| Operational conditions | |||
|---|---|---|---|
| Operating relative humidity (H-H) | 10 - 90% | Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90% | Storage temperature (T-T) | -40 - 70 °C |
| Other features | |||
|---|---|---|---|
| Connectivity LEDs | Yes | Power supply type | 48VDC / 1.25A |
| Connectivity technology | Wired | Dimensions (WxDxH) | 171 x 98 x 27 mm |
| Dimensions (W x D x H) (imperial) | 170.2 x 99.1 x 27.9 mm (6.7 x 3.9 x 1.1") | Network cabling | Cat 3/4/5/5.5e |
| Bandwidth | 1.6 Gbit/s | ||
