Item model number: TL-SG108PE
  • 8 10/100/1000Mbps RJ45 ports
  • With 4 PoE ports, data and power can be transferred on one single cable
  • Provides network monitoring, traffic prioritization and VLAN features
  • Simple network set-up on top of plug-and-play connectivity
  • Web-based user interface and Easy Smart Configuration Utility simplify configuration




Management features
Switch type Unmanaged network switch
Ports & interfaces
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000) Basic switching RJ-45 Ethernet ports quantity 8
Networking
VLAN support Yes Rate limiting Yes
Broadcast storm control Yes Networking standards IEEE 802.1Q,IEEE 802.1p,IEEE 802.3ab,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x
Port mirroring Yes Link aggregation Yes
Data transmission
Packet forwarding rate (1 Gbps) 11900000 pps Jumbo frames 15
Jumbo frames support Yes MAC address table 4000 entries
Switching capacity 16 Gbit/s Number of VLANs 32
Security
IGMP snooping Yes Loop protection Yes
Design
Certification CE, FCC LED indicators Activity, Link, PoE, Power, Speed, Status
Performance
Packet buffer memory 1.5 MB
Power
Output current 1.25 A Output voltage 48 V
AC input frequency 50 AC input voltage 220
Power consumption (max) 65.2 W
Power over Ethernet (PoE)
Power over Ethernet (PoE) voltage range 220 - 220 V Power over Ethernet (PoE) ports quantity 4
Total Power over Ethernet (PoE) budget 55 W Power over Ethernet plus (PoE+) ports quantity 4
Power over Ethernet (PoE) Yes
Weight & dimensions
Width 158 mm Height 25 mm
Depth 101 mm
Packaging content
User guide Yes
