Item model number: TB3DK2DPPD
  • Supports USB Power Delivery 2.0 and includes a 170W power adapter to power and charge (up to 85W) your MacBook Pro or Windows-based laptop, and power your peripheral devices
  • Includes USB-C to DisplayPort cable (with extended length of 6 ft. /1.8 m) to easily connect a second DisplayPort monitor from the Thunderbolt 3 port
  • Supports dual-4K monitors, with 3840 x 2160p or 4096 x 2160p on each display
  • Improve your workflow with single-cable docking and up to 40Gbps bandwidth — twice the speed of Thunderbolt 2 (20Gbps) and eight times faster than USB 3.0 (5Gbps)
  • Connects to your laptop’s Thunderbolt 3 USB-C port, so you can access multiple displays and peripherals
  • Thunderbolt Certified and includes a Thunderbolt 3 host cable (0.5 m)
  • Provides three USB 3.0 ports (USB-C, 2x USB-A), two Thunderbolt 3 USB-C ports, 3.5 mm audio out, 3.5 mm microphone in, and Gigabit Ethernet
  • Fast charge your phone or tablet with the always-on USB 3.0 fast-charge and sync port
  • Works with macOS Sierra (or later), as well as Windows 7 (or later)




Ports & interfaces
Headphone outputs 1 Microphone in Yes
DisplayPorts quantity 1 Thunderbolt 3 ports quantity 2
Ethernet LAN (RJ-45) ports 1 USB 3.0 (3.1 Gen 1) Type-A ports quantity 2
DC-in jack Yes Connectivity technology Cable
Host interface USB 3.0 (3.1 Gen 1) Type-C
Networking
Ethernet LAN Yes Networking standards IEEE 802.3,IEEE 802.3ab,IEEE 802.3u
Ethernet LAN data rates 10,100,1000 Mbit/s
Storage
Card reader integrated No
Performance
Number of displays supported 2 Full duplex Yes
Brand compatibility Universal Data transfer rate 40 Gbit/s
USB data transfer rates 480,5000 Mbit/s Charging function Yes
Auto MDI/MDI-X Yes Maximum digital resolution 4096 x 2160 pixels
UASP support Yes
Power
Input current 2.5 Output voltage 20 V
AC input voltage 100 - 240
Power
Output current 8.5 A Power consumption (typical) 170 W
Design
Certification CE, FCC Colour of product Black, Grey
Material Aluminium, Plastic RoHS compliance Yes
Software
Mac operating systems supported Mac OS X 10.12 Sierra Mac compatibility Yes
Windows operating systems supported Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 Pro,Windows 10 Pro x64,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64
Operational conditions
Operating relative humidity (H-H) 5 - 95% Operating temperature (T-T) 5 - 40 °C
Storage temperature (T-T) -40 - 70 °C
Weight & dimensions
Width 80 mm Package weight 1.5 kg
Package height 88 mm Height 27 mm
Package depth 248 mm Depth 220 mm
Package width 148 mm Weight 450 g
Packaging content
Manual Yes AC adapter included Yes
Cables included AC, Thunderbolt, USB Type-C
Other features
Chipset Intel - Alpine Ridge DSL6540, Fresco Logic - FL1100EX, Texas Instruments - PCM2912A, Intel - WGI210AT
