Item model number: TB3DOCK2DPPD
  • Universal dock turns your MacBook Pro or Windows laptop, with Thunderbolt 3 port, into a dual-4K monitor workstation
  • Supports USB Power Delivery 2.0 to power and charge your laptop (up to 85W), and power your peripherals (includes a robust 180W power adapter)
  • Includes a USB-C to DisplayPort cable (6 ft./1.8 m) for connecting a second DisplayPort monitor to the Thunderbolt 3 port
  • Connect multiple peripherals with 6 USB 3.0 ports (USB 3.1 Gen 1) - (5x USB-A including 1x Fast-Charge and Sync, 1x USB-C)
  • SD and microSD (with adapter) memory card reader, on front of dock, supports SD 4.0 and UHS-II (backward compatible with older SD card versions)
  • Supports PXE network booting
  • Improve your workflow with single-cable docking and up to 40Gbps bandwidth
  • Supports dual 4K Ultra HD external monitors at 60Hz
  • Supports 5K on single monitor (using Thunderbolt 3 and DP connections)
  • Dock and undock quickly, with a single cable for data, power, and external displays
  • Natively supported in macOS Sierra (10.12), macOS High Sierra (10.13) and Windows 8 and 10, without the need for drivers
  • Two Thunderbolt 3 ports to allow for daisy-chaining additional TB devices




Ports & interfaces
Headphone connectivity 3.5 mm Headphone outputs 1
DisplayPorts quantity 1 Thunderbolt 3 ports quantity 2
Ethernet LAN (RJ-45) ports 1 USB 3.0 (3.1 Gen 1) Type-A ports quantity 5
Connectivity technology Cable Combo headphone/mic port Yes
Host interface USB 3.0 (3.1 Gen 1) Type-C
Networking
Ethernet LAN Yes Ethernet LAN data rates 10,100,1000 Mbit/s
Storage
Card reader integrated Yes Compatible memory cards MMC,MicroSDHC,MicroSDXC,SD,SDHC,SDXC
Performance
Full duplex Yes Data transfer rate 40 Gbit/s
Auto MDI/MDI-X Yes Maximum digital resolution 5120 x 2880 pixels
UASP support Yes
Power
Power consumption (standby) 180 W Input current 2.5
Compatible power plug types AU, JP, US Output current 9 A
Output voltage 20 V AC input voltage 100 - 240
Plug type Type N (BR)
Design
Certification CE, FCC Colour of product Black
Material Aluminium RoHS compliance Yes
Software
Mac operating systems supported Mac OS X 10.12 Sierra Mac compatibility Yes
Windows operating systems supported Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 Pro,Windows 10 Pro x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64
Operational conditions
Operating relative humidity (H-H) 0 - 95% Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -20 - 70 °C
Weight & dimensions
Width 87 mm Package weight 1.5 kg
Package height 90 mm Height 34 mm
Package depth 295 mm Depth 222 mm
Package width 145 mm Weight 492 g
Packaging content
Manual Yes AC adapter included Yes
Cables included AC, Thunderbolt, USB Type-C
Other features
Chipset Intel - Alpine Ridge JHL6540, Texas Instruments - TPS65983, Fresco - FL1100EX, Intel - WGI210AT, C-Media - CM6533, Genesys Logic - GL3226
