Item model number: RS232EXTC1
  • Extend RS232 up to 1000m / 3300ft
  • Data transfer rates of up to 230Kbps
  • Compatible with all RS232 communications
  • Employ existing Cat 5, 5e, 6 or better Ethernet infrastructure to remotely connect serial devices
  • Supports full-duplex data communication
  • Compact design
  • No driver software required for easy Plug-and-Play installation




Performance
Maximum transfer distance 1000 m Cable types supported Cat5
Type Network receiver
Networking
Cabling technology 10/100Base-T(X)
Ports & interfaces
Ethernet LAN (RJ-45) ports 2
Design
RoHS compliance Yes Colour of product Silver
Power
Input current 0.055 Output voltage 9 V
Operational conditions
Operating relative humidity (H-H) 0 - 95% Operating temperature (T-T) 0 - 70 °C
Storage temperature (T-T) 0 - 85 °C
Weight & dimensions
Width 34 mm Height 22 mm
Depth 92 mm Weight 65 g
Packaging data
Package height 138 mm Package depth 315 mm
Package width 57 mm
