StarTech.com
StarTech Network 4Port Gigabit Ethernet PCI Express PCIe Network Card Intel I350 NIC Retail (ST4000SPEXI)
$281.98 CAD
/
Shipping calculated at checkout.
Item model number: ST4000SPEXI
- Add four 10/100/1000 RJ-45 Ethernet ports to a client, server or desktop through one PCIe slot
- Intel I350-AM4 chipset with Intel® Virtualization Technology for connectivity
- PXE network boot
- Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
- Auto MDIX support
- Autonegotiation support
- Wake-on-LAN support
- Up to 9K jumbo frame support
- IEEE802.3az Energy Efficient Ethernet (EEE)
- Supports IEEE 802.1Q VLAN tagging
- Full or low-profile (LP bracket included) installation
- Full duplex support
Specification
| Ports & interfaces | |||
|---|---|---|---|
| Ethernet LAN (RJ-45) ports | 4 | Internal | Yes |
| Interface | Ethernet | Connectivity technology | Wired |
| Host interface | PCI-E | ||
| Bandwidth | |||
|---|---|---|---|
| Full duplex | Yes | Data transfer rate (max) | 2000 Mbit/s |
| Networking | |||
|---|---|---|---|
| VLAN tagging | Yes | Cabling technology | 10/100/1000BaseT(X) |
| Ethernet LAN | Yes | Jumbo frames support | Yes |
| Networking standards | IEEE 802.1Q,IEEE 802.3,IEEE 802.3ab,IEEE 802.3u,IEEE 802.3x | Chipset | Intel I350-AM4 |
| Power | |||
|---|---|---|---|
| Power consumption (typical) | 4.4 W | ||
| Design | |||
|---|---|---|---|
| Colour of product | Black, Metallic | LED indicators | Activity, Link |
| Performance | |||
|---|---|---|---|
| Auto MDIX IEEE | Yes | Wake-on-LAN ready | Yes |
| Windows operating systems supported | Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 Pro,Windows 10 Pro x64,Windows 2000,Windows 2000 Professional,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64,Windows Vista Business,Windows Vista Business x64,Windows Vista Enterprise,Windows Vista Enterprise x64,Windows Vista Home Basic,Windows Vista Home Basic x64,Windows Vista Home Premium,Windows Vista Home Premium x64,Windows Vista Ultimate,Windows Vista Ultimate x64,Windows XP Home,Windows XP Home x64,Windows XP Professional,Windows XP Professional x64 | ||
| Performance | |||
|---|---|---|---|
| Linux operating systems supported | Yes | Server operating systems supported | Windows Server 2008 R2,Windows Server 2012 |
| Weight & dimensions | |||
|---|---|---|---|
| Width | 18 mm | Package weight | 168 g |
| Package height | 30 mm | Height | 120 mm |
| Package depth | 170 mm | Depth | 132 mm |
| Package width | 142 mm | Weight | 95 g |
| Certificates | |||
|---|---|---|---|
| Certification | CE, FCC | RoHS compliance | Yes |
| Operational conditions | |||
|---|---|---|---|
| Operating relative humidity (H-H) | 20 - 80% | Operating temperature (T-T) | 5 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C | ||
| Packaging content | |||
|---|---|---|---|
| Manual | Yes | Mounting brackets included | Yes |
| Low-profile bracket | Yes | ||
