Item model number: ST10GPEXNDPI
  • 2-port 10GBase-T/NBASE-T network card supporting five network speeds: 10G, 5G, 2.5G 1G and 100Mbps
  • Reliable performance with Intel® X550 chipset
  • IEEE 802.3az compliant energy-efficient chipset
  • Virtualization (Microsoft Hyper-V®) and iSCSI support
  • PXE support
  • PCIe 3.0 x4 interface
  • Supports 2.5 and 5Gbps network speeds on Cat5e cabling, and 10Gbps on Cat6a
  • Up to 9K jumbo frame support
  • Supports 802.1q VLAN Tagging
  • Full-duplex support
  • Supports Auto-MDIX
  • Supports checksum offload (IP, TCP, UDP) and large send offload
  • Configured with a standard-profile bracket, includes a low profile/half-height bracket




Ports & interfaces
PCI version 3.0 Ethernet LAN (RJ-45) ports 2
Internal Yes Connectivity technology Wired
Host interface PCI-E
Bandwidth
Full duplex Yes Data transfer rate (max) 10000 Mbit/s
Networking
VLAN tagging Yes Cabling technology 10GBase-T
Ethernet LAN Yes Flow control support Yes
Jumbo frames 9000 Jumbo frames support Yes
iSCSI support Yes Networking standards IEEE 802.1Q,IEEE 802.3ab,IEEE 802.3an,IEEE 802.3u,IEEE 802.3x
Chipset Intel X550AT Ethernet LAN data rates 10,100,1000,2500,5000,10000 Mbit/s
Design
Colour of product Black LED indicators Activity, Link, Speed
Performance
Auto MDIX IEEE Yes
Performance
Linux operating systems supported Yes Server operating systems supported Windows Server 2008 R2,Windows Server 2012,Windows Server 2012 R2,Windows Server 2016
Windows operating systems supported Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 Pro,Windows 10 Pro x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64
Weight & dimensions
Width 120 mm Package weight 200 g
Package height 18 mm Height 18 mm
Package depth 150 mm Depth 150 mm
Package width 120 mm Weight 215 g
Certificates
Certification CE, FCC RoHS compliance Yes
Operational conditions
Operating relative humidity (H-H) 20 - 80% Operating temperature (T-T) 5 - 50 °C
Storage temperature (T-T) -20 - 60 °C
Packaging content
Low-profile bracket Yes Quick start guide Yes
