Item model number: ST2000SPEXI
  • Two 10/100/1000Mbps compatible RJ-45 Ethernet ports
  • Fully Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE802.3ad (link aggregation) and supports IEEE 802.1Q VLAN tagging
  • Jumbo Frame support up to 9k bytes
  • Teaming Support
  • Supports Checksum Offload (IP, TCP, UDP), Transmit Segmentation Offload (TCP, UDP) and Large send Offload
  • Wake-on-LAN / Remote Wake-up support
  • Configured with standard profile bracket, low profile/half-height bracket included
  • Supports Intel® Virtualization Technology (VT-c, VMDq, SR-IOV)
  • Four-lane (x4) PCI Express compatible with x4, x8 and x16 PCIe slots
  • Compatible with PCI Express Base Specification 2.1 (backward compatible with 1.0a/1.1)




Ports & interfaces
PCI version 2.1 Ethernet LAN (RJ-45) ports 2
Internal Yes Interface Ethernet
Connectivity technology Wired Host interface PCI-E
Bandwidth
Full duplex Yes Data transfer rate (max) 2000 Mbit/s
Networking
LAN controller Intel I350AM2 VLAN tagging Yes
Cabling technology 10/100/1000BaseT(X) Ethernet LAN Yes
Jumbo frames 9000 Jumbo frames support Yes
Networking standards IEEE 802.1Q,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3u Chipset Intel - I350-AM2
Ethernet LAN data rates 10,100,1000 Mbit/s
Design
Colour of product Aluminium, Black LED indicators Activity, Link
Performance
Auto MDIX IEEE Yes Wake-on-LAN ready Yes
Windows operating systems supported Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 Pro,Windows 10 Pro x64,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64,Windows Vista Business,Windows Vista Business x64,Windows Vista Enterprise,Windows Vista Enterprise x64,Windows Vista Home Basic,Windows Vista Home Basic x64,Windows Vista Home Premium,Windows Vista Home Premium x64,Windows Vista Ultimate,Windows Vista Ultimate x64,Windows XP Home,Windows XP Home x64,Windows XP Professional,Windows XP Professional x64
Performance
Linux operating systems supported Yes Server operating systems supported Windows Server 2003,Windows Server 2008 R2,Windows Server 2012
System requirements
Recommended usage Server
Weight & dimensions
Width 19 mm Package weight 166 g
Package height 28 mm Height 121 mm
Package depth 167 mm Depth 67 mm
Package width 140 mm Weight 80 g
Certificates
Certification CE, FCC RoHS compliance Yes
Operational conditions
Operating relative humidity (H-H) 5 - 85% Operating temperature (T-T) 0 - 50 °C
Storage temperature (T-T) -20 - 60 °C
Packaging content
Manual Yes Drivers included Yes
Low-profile bracket Yes
Other features
Power LED Yes Link/Act LED Yes
