Item model number: SV231DPDDUA
  • Native dual DisplayPort connections - no adapter required
  • Supports 2560x1600 @ 60Hz resolutions; beyond 1080p
  • Maximum resolutions of 3840x2400 at lower refresh rates
  • 7.1 Channel High Definition Digital Audio supported via the DisplayPort interface
  • 3.5mm 2-channel stereo audio and microphone
  • Integrated 2 port hub for USB 2.0 peripheral sharing
  • No driver or software installation required
  • OS Independent
  • Hotkey and push-button switching
  • Full plug-and-play support with USB console interfaces
  • User-defined scan time intervals
  • Audio can be switched independently
  • Supports hot-plug, un-plug and link status-failure detection
  • Supports DDC2B for monitor detection
  • VESA and CEA compliant
  • Small form factor design with rear connection ports




Networking
Ethernet LAN No
Ports & interfaces
Console USB ports quantity 2 Audio connections Yes
Number of microphone inputs 3 USB 2.0 hub ports quantity 2
Console ports 3.5mm headphone, 3.5mm mic, DisplayPort, USB A Headphone outputs 3
DisplayPorts quantity 6 Video port type DisplayPort
Mouse port type USB Keyboard port type USB
USB connector type USB Type-A DC-in jack Yes
Number of computers controlled 2
Video
HD type 4K Ultra HD Maximum resolution 3840 x 2400 pixels
Design
Rack mounting No Hot keys Yes
Material Steel Colour of product Black
Push button Yes LED indicators Yes
Display
On Screen Display (OSD) No Built-in display No
Performance
Number of users 1 user(s) Hot-Plug support Yes
DDC2B support Yes Daisy chain No
Performance
Audio channels 7.1
Power
Compatible power plug types AU,EU,UK,US Plug type Type M
Output current 1.5 A Output voltage 12 V
External power adapter Yes Input current 0.8
AC input voltage 110 - 240 Power consumption (typical) 18 W
Technical details
USB hub Yes
Operational conditions
Operating relative humidity (H-H) 0 - 80% Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) 20 - 60 °C
Certificates
Certification CE, FCC RoHS compliance Yes
Weight & dimensions
Width 161 mm Package weight 1.3 kg
Package height 181 mm Height 57.5 mm
Package depth 250 mm Depth 100 mm
Package width 100 mm Weight 1.2 kg
Packaging content
Manual Yes
Other features
Audio support Yes IP control No
