Item model number: SAT32M225
  • Open-frame steel mounting bracket
  • Supports 7mm or larger 2.5" SATA bays
  • Supports B key M.2 SSDs
  • Support for SATA revision I/II/III (1.5/3.0/6.0 Gbps)
  • 2.5in SATA form factor housing
  • Supports full length M.2 SSD Solid State Drives (2230, 2242, 2260, 2280)
  • NOT compatible with M.2 NVMe or AHCI PCI-Express SSDs




Ports & interfaces
Output interface M.2 SATA revision 3.0
Internal Yes Host interface SATA
Performance
Data transfer rate (max) 6 Gbit/s Hot-swap No
Design
RoHS compliance Yes Colour of product Green
Certification CE, FCC
System requirements
Windows operating systems supported Yes
System requirements
Mac operating systems supported Yes Linux operating systems supported Yes
Operational conditions
Operating temperature (T-T) -40 - 85 °C
Weight & dimensions
Width 70 mm Package weight 104 g
Package height 30 mm Height 7 mm
Package depth 142 mm Depth 100 mm
Package width 170 mm Weight 38 g
Packaging content
Manual Yes
