Item model number: PEXUSB3S2EI
  • Flexibility to connect external and internal USB 3.0 devices and supports UASP
  • Fast, hassle-free setup with Windows 8 native support, and fits into standard or low-profile systems
  • Backward compatibility lets you save money and connect existing USB 2.0 and 1.x devices
  • Transfer large files at lightning speed, with throughput support up to 5 Gbps
  • Optional SATA power connector provides up to 900mA per port for high-power USB devices
  • PCIe x1 interface, compliant with PCI Express 2.0 specifications
  • Configured with full-profile bracket, half-height bracket included




Ports & interfaces
Internal SATA ports quantity 1 USB 3.0 (3.1 Gen 1) Type-A ports quantity 2
Output interface SATA,USB 3.0 Internal Yes
PCI Card form factor Full-height (low-profile) Host interface PCIe
Performance
Data transfer rate (max) 5 Gbit/s Maximum cable length 3 m
UASP support Yes Chipset Renesas / NEC - µPD720201
Design
Mean time between failures (MTBF) 1920042 h RoHS compliance Yes
Colour of product Metallic, Red Certification CE, FCC
System requirements
Windows operating systems supported Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64,Windows Vista Business,Windows Vista Business x64,Windows Vista Enterprise,Windows Vista Enterprise x64,Windows Vista Home Basic,Windows Vista Home Basic x64,Windows Vista Home Premium,Windows Vista Home Premium x64,Windows Vista Ultimate,Windows Vista Ultimate x64,Windows XP Home,Windows XP Home x64,Windows XP Professional,Windows XP Professional x64
System requirements
Linux operating systems supported Yes Server operating systems supported Windows Server 2008 R2,Windows Server 2012
Operational conditions
Operating relative humidity (H-H) 20 - 80% Operating temperature (T-T) 5 - 50 °C
Storage temperature (T-T) -25 - 70 °C
Weight & dimensions
Width 18 mm Package weight 140 g
Package height 30 mm Height 120 mm
Package depth 140 mm Depth 92 mm
Package width 142 mm Weight 55 g
Packaging content
Manual Yes Mounting brackets included Yes
Drivers included Yes
