StarTech Accessory EDID Emulator for HDMI Displays 1080p Retail (HB30C3A1GE)
$87.98 CAD
/
Shipping calculated at checkout.
Item model number: HB30C3A1GE
- Expand your laptop’s connectivity through USB-C by adding three USB-A ports (5Gbps) and a GbE RJ45 port
- Compact, small-footprint design makes it perfect for travel, or for desktop placement
- Built-in, extended length (30 cm) USB Type-C cable, for flexible desk placement options
- .
- Included power adapter ensures your connected devices are fully powered and operational
- Integrated cable features a small and reversible USB-C connector, and it’s Thunderbolt 3 data port compatible
- Fast, easy installation with native support in most operating systems
- Supports Wake-On-LAN, Energy-Efficient Ethernet, jumbo frames, full duplex flow control, VLAN tagging, and layer 2 priority encoding
- Backward compatible, for use with your older USB 3.0 and 2.0 devices
- Dongle-style combination hub provides three SuperSpeed USB 3.0 (USB 3.1 Gen 1) ports, with throughput support up to 5Gbps
- Plug-and-play and hot-swap compatible
Specification
| Ports & interfaces | |||
|---|---|---|---|
| Ethernet LAN (RJ-45) ports | 1 | USB 3.0 (3.1 Gen 1) Type-A hub ports quantity | 3 |
| USB version | 3.0 (3.1 Gen 1) | Internal | No |
| Interface | Ethernet | Connectivity technology | Wired |
| Host interface | USB | ||
| Bandwidth | |||
|---|---|---|---|
| Full duplex | Yes | Data transfer rate (max) | 1000 Mbit/s |
| Networking | |||
|---|---|---|---|
| VLAN tagging | Yes | Flow control support | Yes |
| Jumbo frames | 4000 | Jumbo frames support | Yes |
| Networking standards | IEEE 802.1Q,IEEE 802.1p,IEEE 802.3,IEEE 802.3ab,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x | Chipset | Genesys Logic - GL3522 (USB 3.0), ASIX - AX88179 (LAN) |
| Power | |||
|---|---|---|---|
| Power consumption (typical) | 10 W | Input current | 0.5 |
| Input voltage | 100-240 | Output current | 2 A |
| Output voltage | 5 V | Plug type | Type H (IL) |
| Design | |||
|---|---|---|---|
| Housing material | Plastic | Colour of product | Black |
| LED indicators | Activity, Link | ||
| Performance | |||
|---|---|---|---|
| Auto MDIX IEEE | Yes | Wake-on-LAN ready | Yes |
| Performance | |||
|---|---|---|---|
| Mac operating systems supported | Mac OS X 10.10 Yosemite,Mac OS X 10.11 El Capitan,Mac OS X 10.6 Snow Leopard,Mac OS X 10.7 Lion,Mac OS X 10.8 Mountain Lion,Mac OS X 10.9 Mavericks | Hot-swap | Yes |
| Other operating systems supported | Chrome | Server operating systems supported | Windows Server 2008 R2,Windows Server 2012 |
| Plug and Play | Yes | Auto-negotiation | Yes |
| Windows operating systems supported | Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 Pro,Windows 10 Pro x64,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64,Windows Vista Business,Windows Vista Business x64,Windows Vista Enterprise,Windows Vista Enterprise x64,Windows Vista Home Basic,Windows Vista Home Basic x64,Windows Vista Home Premium,Windows Vista Home Premium x64,Windows Vista Ultimate,Windows Vista Ultimate x64 | Cable length | 0.3 m |
| Weight & dimensions | |||
|---|---|---|---|
| Width | 45 mm | Package weight | 337 g |
| Package height | 51 mm | Height | 14 mm |
| Package depth | 213 mm | Depth | 87 mm |
| Package width | 149 mm | Weight | 50 g |
| Certificates | |||
|---|---|---|---|
| Certification | CE, FCC | RoHS compliance | Yes |
| Operational conditions | |||
|---|---|---|---|
| Operating relative humidity (H-H) | 0 - 85% | Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -10 - 70 °C | ||
| Packaging content | |||
|---|---|---|---|
| AC adapter included | Yes | Included power plug types | AU,EU,NA,UK |
