Item model number: ST124HD4K
  • Supports Ultra HD video resolutions up to 4K @ 30Hz
  • Support for 7.1 surround sound audio
  • 4x HDMI outputs
  • Solid aluminum housing
  • Small footprint
  • EDID emulation




Ports & interfaces
Video port type HDMI Video ports quantity 4
Video
Supported graphics resolutions 1280 x 720 (HD 720),1920 x 1080 (HD 1080),1920 x 1200 (WUXGA),2560 x 1600 (WQXGA) Maximum resolution 3840 x 2160 pixels
Full HD Yes Supported video modes 720p,1080p,2160p
HD-Ready Yes
Colour
Colour of product Black
Power
Input current 0.35 Input voltage 100-240
Output current 1 A Output voltage 5 V
Operational conditions
Storage temperature (T-T) -10 - 80 °C Operating temperature (T-T) 0 - 70 °C
Operational conditions
Operating relative humidity (H-H) 5 - 90%
Certificates
Certification CE, FCC, RoHS
Indication
LED indicators Activity, Power Power LED Yes
Technical details
Housing material Aluminium Audio support Yes
HDMI version 1.4 Supported audio channels 7.1
Weight & dimensions
Package length 21.8 cm Package weight 600 g
Package height 52 mm Dimensions (WxDxH) 84 x 139 x 14 mm
Package width 148 mm Weight 277 g
Packaging content
Manual Yes AC adapter included Yes
