Item model number: ST122HDMI2
  • Splits an HDMI source signal to two displays, with no loss of signal quality
  • Supports resolutions up to 1080p (1920x1200)
  • Supports HDMI audio or separate 3.5mm stereo audio connection
  • Rugged steel enclosure
  • Can be cascaded up to 3 layers
  • High Speed HDMI®, HDCP and EDID Compliant
  • LED indicators for signal activity monitoring




Ports & interfaces
Video port type HDMI Video ports quantity 2
Audio ports quantity 2
Video
Maximum resolution 1920 x 1200 pixels Full HD Yes
Colour
Colour of product Black
Power
Input voltage 115-230 Output current 2.6 A
Output voltage 5 V
Operational conditions
Storage temperature (T-T) -20 - 60 °C Operating temperature (T-T) 0 - 40 °C
Operational conditions
Operating relative humidity (H-H) 0 - 80%
Indication
LED indicators Yes
Technical details
Housing material Steel Maximum cable length 15 m
Weight & dimensions
Package length 22.2 cm Package weight 700 g
Package height 100 mm Dimensions (WxDxH) 183 x 80 x 25 mm
Package width 100 mm Weight 380 g
Packaging content
Manual Yes AC adapter included Yes
