Item model number: PEXUSB3S24
  • Provides two external USB 3.0 ports with UASP support
  • Supports data rates up to 5 Gbps
  • Compliant with PCI Express 2.0 specifications
  • Optional SATA power connector provides up to 900mA per USB port
  • Supports USB Battery Charging Specification 1.2
  • Fully compliant with USB 3.0 rev 1.0 and Intel xHCI rev 1.0 specifications
  • Backward compatible with USB 2.0 and USB 1.0/1.1 devices
  • Includes a Low-Profile/half-height installation bracket




Ports & interfaces
ExpressCard slot No USB 3.0 (3.1 Gen 1) Type-A ports quantity 2
Output interface USB 3.0 Internal Yes
PCI Card form factor Half-height (low-profile) Host interface PCIe
Performance
Data transfer rate (max) 5 Gbit/s
Design
Colour of product Green, Metallic
System requirements
Windows operating systems supported Yes
System requirements
Linux operating systems supported Yes
Operational conditions
Operating relative humidity (H-H) 20 - 80% Operating temperature (T-T) 5 - 50 °C
Storage temperature (T-T) -25 - 70 °C
Weight & dimensions
Width 40 mm Package height 30 mm
Height 60 mm Package depth 175 mm
Depth 65 mm Package width 142 mm
Weight 130 g
