Item model number: DISPLPORT10L
  • High-resolution support up to 4K x 2K
  • Support for High Bit Rate 2 (HBR2) bandwidth of up to 21.6Gbps
  • DisplayPort (VESA) certified
  • More Features . . .
  • Backward compatible with DisplayPort 1.1
  • Designed and manufactured to DisplayPort 1.2 standards
  • Supports the DPCP (DisplayPort Content Protection) standard in addition to HDCP
  • Molded latching connectors with strain relief




Features
Jacket material Polyvinyl chloride (PVC) Cable shielding Aluminum mylar foil
Latching connectors Yes Connector 1 gender Male
Cable length 3 m AWG wire size 28
Connector 2 gender Male Connector contacts plating Nickel
Cable rating CMG (CM) Colour of product Black
Connector 1 DisplayPort Connector 2 DisplayPort
DisplayPort version 1.2
Features
DisplayPort Content Protection (DPCP) Yes HDCP Yes
Maximum resolution 3840 x 2160 pixels Plug and Play Yes
RoHS compliance Yes Number of conductors 19
Bandwidth 21600 MB/s
Weight & dimensions
Package weight 200 g Package height 315 mm
Package depth 242 mm Package width 24 mm
Cable diameter 7.3 mm
Packaging content
Quantity per pack 1
