Item model number: ST1030USBM
  • Add ten USB 3.0 (5Gbps) ports with this DIN rail or surface-mountable metal hub
  • 10 Port USB Hub with 15kV ESD & 350W Surge Protection
  • DIN Rail / Wall-Mountable USB Hub w/ Metal Housing / Rugged and heavy-duty hub thats perfect for tough factory settings
  • 10 port SuperSpeed USB 3 hub offers wide-range 7-24V DC terminal block power input
  • Extended operating temperature range / Ideal for harsh environments / Optional DIN rail mounts included / Backward compatible




Ports & interfaces
Hub interfaces USB 3.0 (3.1 Gen 1) Type-A Terminal block port Yes
USB 3.0 (3.1 Gen 1) Type-A ports quantity 10 Ports quantity 10
Host interface USB 3.0 (3.1 Gen 1) Type-B
Performance
Surge protection Yes Data transfer rate 5000 Mbit/s
Certification RoHS, CE, FCC
Power
Input voltage 7-24
Design
Material Steel Colour of product Black
LED indicators Power
Operational conditions
Operating temperature (T-T) 0 - 70 °C
Operational conditions
Operating relative humidity (H-H) 5 - 95% Storage temperature (T-T) -20 - 85 °C
Weight & dimensions
Width 56 mm Package weight 567 g
Package height 55 mm Height 31 mm
Package depth 245 mm Depth 198 mm
Package width 162 mm Weight 343 g
Packaging content
Manual Yes Cables included USB
Terminal block included Yes
Other features
Chipset Genesys Logic - GL3520
