Item model number: MCM110ST2
  • Supports a maximum multi mode fiber optic cable distance of 2 km
  • Supports full or half-duplex operation
  • Compatible with 3COM™, Cisco™, Lucent™ and Nortel™ networks
  • Supports Link Fault Pass through (LFP)
  • Supports IEEE 802.3 10Base-T, 802.3u 100Base-TX and 100Base-FX industry standards
  • Supports IEEE 802.1q Tag VLAN pass thru
  • Supports Q in Q double tagged frame transparent
  • LED Indicators for simple Ethernet/Fiber network link monitoring
  • Support flow control (Pause)




Networking
Cabling technology 10Base-T, 100Base-FX, 100Base-TX Data transfer rate (max) 100 Mbit/s
Ports & interfaces
Connectivity technology Wired
Performance
Wavelength 1310 nm Maximum transfer distance 2000 m
Design
LED indicators Yes
Operational conditions
Storage temperature (T-T) -10 - 70 °C Operating temperature (T-T) 0 - 50 °C
Operational conditions
Operating relative humidity (H-H) 10 - 90%
Weight & dimensions
Package weight 410 g Package height 145 mm
Package depth 148 mm Package width 63 mm
Weight 90.5 g
Other features
Connector(s) ST Power requirements 115 VAC, 12 VDC
Compliance industry standards IEEE 802.3, IEEE 802.3u Dimensions (WxDxH) 75 x 95 x 20 mm
Full duplex Yes
