Item model number: NETRS2321POE
  • PoE support gives you the freedom to situate your serial device where it is needed even when no power outlet is available
  • IP-based connection to your serial devices allows remote administration from anywhere; even over the Internet
  • Remotely connect to multiple NETRS2321POE units with a single PC for simple and efficient management of devices from a single location
  • Supports standard Ethernet or Power over Ethernet (POE)
  • Supports UDP, IP, TCP, ICMP, HTTP, DHCP and ARP-Ping protocols




Technical details
Data transfer rate 0.1152 Mbit/s Serial interface type RS-232
Networking standards IEEE 802.3af Serial ports quantity 1
Ethernet LAN data rates 10,100 Mbit/s
Ports & interfaces
Cabling technology 10/100Base-T(X) Ethernet LAN (RJ-45) ports 1
Design
Certification CE, FCC, RoHS
Other features
Compatible operating systems Win2000, Win XP 32bit, Vista 32bit
Operational conditions
Storage temperature (T-T) -20 - 85 °C Operating temperature (T-T) 0 - 55 °C
Operational conditions
Operating relative humidity (H-H) 5 - 95%
Weight & dimensions
Package height 158 mm Dimensions (WxDxH) 66.3 x 107 x 25.4 mm
Package width 55 mm Weight 480 g
Software
Windows operating systems supported Windows 2000,Windows 2000 Professional,Windows Vista Business,Windows Vista Enterprise,Windows Vista Home Basic,Windows Vista Home Premium,Windows Vista Ultimate,Windows XP Home,Windows XP Professional
Indication
Link/Act LED Yes
Protocols
Supported network protocols UDP, IP, TCP, ICMP, HTTP, DHCP, ARP-Ping
Power
Power consumption 100 mA Input voltage 12
