Item model number: KVR16LS11/8
VLSKU: 103412
  • RAM Type:DRAM
  • RAM / Technology:DDR3 SDRAM
  • RAM Form Factor:SODIMM
  • RAM / Storage Capacity:8 GB
  • RAM / Memory Speed:1600 MHz
  • Memory / Supply Voltage:1.35 V
  • Energy Star Compliant:null




Memory
Internal memory 8 GB Row cycle time 48.125 ns
CAS latency CL11 Memory layout (modules x size) 1 x 8 GB
Component for Notebook ECC No
Lead plating Gold Memory voltage 1.35,1.5 V
Module configuration 1G X 64 Memory form factor 204-pin SO-DIMM
Memory bus 64 bit Internal memory type DDR3L
Registered No Memory clock speed 1600 MHz
Memory
Row active time 35 ns Refresh row cycle time 260 ns
Operational conditions
Operating temperature (T-T) 0 - 85 °C Storage temperature (T-T) -55 - 100 °C
Weight & dimensions
Width 67.6 mm Height 30 mm
Other features
Memory layout 1 x 8192 MB Internal memory 8192 MB
Rack mounting 204-pin SODIMM Warranty note Lifetime
Bus clock rate 1600 MHz Chips organisation X8
Error indication No
