Item model number: T253TD001T3C101
VLSKU: 105307

  • Welcome to the new era of 3D NAND

    Welcome to the new era of 3D NAND

    The latest generation of 3D NAND flash memory has overcome the technical barrier of 2D NAND and has enhanced the overall capacity, performance, and reliability. Unlike the 2D planar flash memory, 3D NAND increases storage capacity by stacking up cells in the vertical direction. It not only provides a better performance and endurance but also breaks through the technical limitation of planar chips.

  • 4 times of speed improvement

    The L5 LITE 3D solid state drive is 4 times faster* than the traditional hard drive. Its excellent performance and read/write speed not only allow fast boot/shutdown time but also speed up the response time of all applications, so consumers can enjoy the high-speed performance immediately after the upgrade. The lightweight and zero hassle advantage make it the best product to replace the traditional hard drive.

    *The speed was tested by TEAMGROUP and for the reference only.

    4 times of speed improvement
  • Lightweight and compact with various capacities for selection

    Lightweight and compact with various capacities for selection

    The L5 LITE 3D solid state drive has an industry-standard 2.5-inch. With the only 7mm in height, it is best suited for Ultrabooks on the market. Whether it is for laptop or desktop, the upgrade can be done quickly. It is using SATA III 6Gbps specification and capacities available in 120GB, 240GB, 480GB, 1TB, etc. With read speed up to 470 MB/s*, it not only improves the computer performance, but it is also the best bargain available.

  • Solid, durable, total protection

    The L5 LITE 3D solid state drive is using 3D NAND flash memory chip, which is durable, shockproof, drop resistant and offers a total protection for the data. Even if you accidentally drop your computer or it landed on a hard surface, it can still prevent damages and data corruption from accidents.

    Solid, durable, total protection
  • Perfect long term operation

    Perfect long term operation

    The L5 LITE 3D solid state drive supports Windows TRIM optimization command which is able to release free blocks, allowing an operating system to use them later immediately when writing data. The optimized access control technology of NCQ can speed up the transfer and write performance of the SSD, and effectively reduces performance degradation and wear and tear of the drive. This can prolong the service life of the SSD perfectly.

  • Trustworthy reliability

    L5 LITE 3D solid state drive's built-in smart algorithm management mechanism has functions such as garbage collection which is able to ensure operational efficiency. The powerful Wear-Leveling technology and ECC (Error Correction Code) function enhance the reliability of data transfer.

    Trustworthy reliability



Features
NVMe No Interface Serial ATA III
TRIM support Yes Write speed 400 MB/s
SSD capacity 1000 GB Windows operating systems supported Windows 10,Windows 7,Windows 8,Windows Vista
Mean time between failures (MTBF) 1000000 h Read speed 500 MB/s
Native Command Queuing (NCQ) Yes S.M.A.R.T. support Yes
ECC Yes Data transfer rate 6 Gbit/s
Random read (4KB) 80000 IOPS Component for PC/notebook
SSD form factor 2.5" Random write (4KB) 70000 IOPS
Features
Mac operating systems supported Yes Linux operating systems supported Yes
Power
Operating voltage 5 V
Operational conditions
Non-operating vibration 20 G Operating shock 1500 G
Operating temperature (T-T) 0 - 70 °C Operating relative humidity (H-H) 5 - 95%
Weight & dimensions
Height 7 mm Width 69.9 mm
Weight 65 g Depth 100 mm
Packaging data
Package type Hanging box
Other features
Product colour Gold
